The Autodesk® Advance Steel software is a powerful 3D modeling application that streamlines the fabrication process through the use of a 3D model, which is used to create fabrication drawings, Bill of Materials (BOM) lists, and files for Numerical Control (NC) machines.
Since structural steel projects are extremely complex, the Autodesk Advance Steel software is also complex. The objective of the Autodesk® Advance Steel 2025: Fundamentals guide is to enable you to create full 3D project models at a high level of detail and set them up in fabrication drawings. This guide focuses on the basic tools that the majority of users need. You begin by learning the user interface, basic 3D viewing tools, and the standard AutoCAD® tools that are routinely used. Specific Autodesk Advance Steel objects, including structural columns, beams, bracing, plates, bolts, anchors, welds, and additional 3D objects are also covered. You will also learn about the powerful model verification tools. To complete the guide, you will learn to edit and generate all of the required documentation files that enable your design to accurately and effectively communicate the final design.
Topics Covered:
• Understand the process of 3D modeling and extracting 2D documentation from a model in the Autodesk Advance Steel software.
• Navigate the Autodesk Advance Steel interface.
• Work with 3D viewing tools.
• Review helpful AutoCAD tools.
• Work with the User Coordinate System (UCS).
• Use the Autodesk Advance Steel Modify commands.
• Add structural grids.
• Create levels.
• Model columns and beams and add bracing.
• Create connections using the Connection Vault.
• Create special parts.
• Verify models using Clash Checking tools.
• Modify a drawing prototype.
• Work within the Drawing Style Manager.
• Create custom connections.
• Create plates and add bolts, anchors, and welds.
• Add grating and cladding.
• Model ladders, stairs, and railings.
• Create concrete objects such as footings.
• Number objects.
• Extract 2D drawings from the model using Drawing Styles and Drawing Processes.
• Review and modify 2D drawings using the Document Manager.
• Modify 2D details with parametric dimensions.
• Revise models and drawings.
• Create BOM lists.
• Export data to .NC and .DXF files.
Prerequisites:
• Access to the 2025.0 version of the software, to ensure compatibility with this guide. Future software updates that are released by Autodesk may include changes that are not reflected in this guide. The practices and files included with this guide are not compatible with prior versions (e.g., 2024).
ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in the following ways:
- Download to a computer (Windows or MAC)
- Access online (via a computer connected to the internet)
- Download to a compatible smart phone or tablet device
Please Note:
- Dual monitors or separate reader device recommended to facilitate use with software.
- eBooks are intended for single-user use only. License restrictions prevent multi-user or network access.
- eBook is not a printable PDF and intended for electronic use only.
- eBooks cannot be returned if license code has been redeemed.
Visit: bookshelf.vitalsource.com to learn more
Instructor Guides are ideal teaching resources that incorporate the following instructional tools within the learning guide: answers to the chapter review questions, suggested timing guide for course delivery, and instructor presentation files.
