The Autodesk® Inventor® 2024: Sheet Metal Design guide introduces the concepts and techniques of sheet metal modeling with the Autodesk Inventor software.
The structure of the guide follows the typical stages of using the Autodesk Inventor software. That is, to create and edit sheet metal parts, generate flat patterns, and document the designs in drawings.
Topics Covered:
- Understanding the Autodesk Inventor Sheet Metal interface and workflow
- Creating base faces, contour flanges, and contour rolls
- Creating secondary faces, contour flanges, and contour rolls
- Working with sheet metal parameters
- Creating flanges
- Adding hems, folds, and bends to sheet metal models
- Adding corner rounds and chamfers to sheet metal models
- Removing geometry from a sheet metal model (holes, cuts, and punch features)
- Controlling sheet metal geometry using corner seams (seams and miters)
- Generating flat patterns
- Creating lofted flanges
- Creating rip features to permit the flattening of the sheet metal geometry
- Unfolding and refolding sheet metal geometry
- Designing multi-body sheet metal models
- Documenting and annotating sheet metal drawings
- Converting solid models to sheet metal models
- Working with sheet metal styles
Prerequisites:
- Access to the 2024.0 version of the software, to ensure compatibility with this guide. Future software updates that are released by Autodesk may include changes that are not reflected in this guide.
- The practices and files included with this guide are not compatible with prior versions (e.g., 2023).
- The material covered in this training guide assumes a mastery of Autodesk Inventor basics as taught in Autodesk Inventor: Introduction to Solid Modeling.
Knowledge of sheet metal processing is an asset, but not required.
ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in the following ways:
- Download to a computer (Windows or MAC)
- Access online (via a computer connected to the internet)
- Download to a compatible smart phone or tablet device
Please Note:
- Dual monitors or separate reader device recommended to facilitate use with software.
- eBooks are intended for single-user use only. License restrictions prevent multi-user or network access.
- eBook is not a printable PDF and intended for electronic use only.
- eBooks cannot be returned if license code has been redeemed.
Visit: bookshelf.vitalsource.com to learn more
Instructor Guides are ideal teaching resources that incorporate the following instructional tools within the learning guide: answers to the chapter review questions, suggested timing guide for course delivery, and instructor presentation files.
