The Autodesk® Moldflow® Insight 2017: Reactive Molding training material discusses the simulations capabilities involving thermosetting materials. There are several processes discussed including Reactive molding (injection molding of thermosetting materials), RTM/SRIM, Reactive Compression molding, and Reactive Injection – Compression Molding. Discussions include an overview of the molding processes and materials, and governing equations. Exercises relate to filling and packing analyses related to thermosetting materials.
Topics Covered:
- Reactive molding Overview.
- Differences between thermoplastic and thermosetting materials.
- Supported analysis types for reactive materials.
- Overview of thermoset materials.
- Reactive analysis with different mesh types.
- Reactive injection compression molding analyses.
- Resin transfer molding analysis.
- Venting analysis with reactive materials.
- Setting mold temperature profiles with reactive materials.
- Reactive Compression molding analysis.
Prerequisites:
This student guide assumes knowledge of Autodesk® Moldflow® Insight 2017, including CAD Model importing, and meshing. Refer to the Autodesk® Moldflow® Insight 2017: Fundamentals student guide for more information on these subjects.
ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in three ways.
- Download your eBook to your personal computer and open it in the free VitalSource Bookshelf application. No Internet connection is required after you download your eBook to the VitalSource Bookshelf.
- Download your eBook to your mobile phone or tablet and open it in the free VitalSource Bookshelf app. Compatible with:
- iPhone, iPod Touch, and iPad (requires iOS 11 or later)
- Android Smart Phones & Tablets (requires Android 5.0 and higher)
- Access your eBook online from any Internet-connected device with a modern browser.
Please Note:
- Dual monitors, tablet, or separate reader device is recommended to facilitate use of the eBook with the software throughout the course.
- eBooks are intended for single user use only. License code restrictions prevent multi-user access or use on networks.
- eBook file is not a printable PDF, and intended for electronic use only.
- eBooks can not be returned if license code has been redeemed.
Visit: bookshelf.vitalsource.com to learn more
