The main purpose of the Autodesk® Revit®
Architecture software is to design buildings: walls, doors, floors, roofs, and
stairs. However, architects also frequently need to add site and structural
information.
The Autodesk®
Revit® 2020 Architecture: Site and Structural Design guide
covers the elements and tools that are used to create topographic surfaces for
site work and add structural elements.
Site Topics Covered
- Create
topographic surfaces.
- Add
property lines and building pads.
- Modify
toposurfaces with subregions, splitting surfaces and grading the regions.
- Annotate
site plans and add site components.
- Work
with Shared Coordinates.
Structural Topics Covered
- Create
structural grids and add columns.
- Add
foundation walls and footings.
- Add
beams and beam systems.
- Create
framing elevations and add braces.
Prerequisites
- Access
to the 2020.0 version of the software, to ensure compatibility with this guide.
Future software updates that are released by Autodesk may include changes that
are not reflected in this guide. The practices and files included with this
guide might not be compatible with prior versions (i.e., 2019).
- Knowledge
of the basic techniques of the fundamentals of the Autodesk Revit Architecture
software covered in the Autodesk®
Revit® 2020: Fundamentals for Architecture guide.
- Information
on the Autodesk® Revit® Structure software, which is
optimized for structural engineering, is covered in Autodesk® Revit® 2020: Fundamentals for Structure
guide.
ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in three ways.
- Download your eBook to your personal computer and open it in the free VitalSource Bookshelf application. No Internet connection is required after you download your eBook to the VitalSource Bookshelf.
- Download your eBook to your mobile phone or tablet and open it in the free VitalSource Bookshelf app. Compatible with:
- iPhone, iPod Touch, and iPad (requires iOS 11 or later)
- Android Smart Phones & Tablets (requires Android 5.0 and higher)
- Access your eBook online from any Internet-connected device with a modern browser.
Please Note:
- Dual monitors, tablet, or separate reader device is recommended to facilitate use of the eBook with the software throughout the course.
- eBooks are intended for single user use only. License code restrictions prevent multi-user access or use on networks.
- eBook file is not a printable PDF, and intended for electronic use only.
- eBooks can not be returned if license code has been redeemed.
Visit: bookshelf.vitalsource.com to learn more
An Instructor Guide provides you with all that you need to teach the training course. It contains all the same instructional content as a Learning Guide, along with the answers to the chapter review questions, timing suggestions to help you in delivering various sections of the course, and instructor presentation files that complement the guide.
