In this guide, you will gain an understanding of the general concepts behind Model-Based Definition (MBD) and why your company is likely moving toward its implementation. You will learn the 3D Annotation tools, which are necessary for using the Creo Parametric software to support Model-Based Definition.
Topics Covered:
• Overview of Model-Based Definition
• The Annotation Interface
• Configuration and Detail Options
• Cross Sections
• Using Combination States
• Semantic and Presentation Annotations
• Working with Legacy Datums
• Adding Dimensions
• Adding Geometric Tolerances
• Adding Notes
• Note Libraries
• Adding Symbols
Prerequisites:
• Access to the Creo Parametric 10.0 version of the software, to ensure compatibility with this guide. The practices and files included with this guide might not be compatible with prior versions (e.g., 8.0.2). The practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Experience in mechanical design and drawing production is recommended.
• It is highly recommended that you have completed the Creo Parametric 10.0: Introduction to Solid Modeling course.
