The Creo Parametric 7.0: Design Documentation and Detailing learning guide is designed for all draftspersons that document designs using Creo Parametric. It focuses on how to use Creo Parametric to communicate design information from your part and assembly models.
This content was developed using Creo Parametric 7.0, Build 7.0.2.0.
Topics Covered:
- View creation
- View manipulation
- Detailing a drawing
- Drawing notes
- Tolerances
- Assembly drawings
- Drawing tables
- 2D sketching
- Symbols
Prerequisites:
- Access to the Creo Parametric 7.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
- Completing Creo Parametric 7.0: Introduction to Solid Modeling or equivalent Creo Parametric 7.0 experience.
ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in three ways.
- Download your eBook to your personal computer and open it in the free VitalSource Bookshelf application. No Internet connection is required after you download your eBook to the VitalSource Bookshelf.
- Download your eBook to your mobile phone or tablet and open it in the free VitalSource Bookshelf app. Compatible with:
- iPhone, iPod Touch, and iPad (requires iOS 11 or later)
- Android Smart Phones & Tablets (requires Android 5.0 and higher)
- Access your eBook online from any Internet-connected device with a modern browser.
Please Note:
- Dual monitors, tablet, or separate reader device is recommended to facilitate use of the eBook with the software throughout the course.
- eBooks are intended for single user use only. License code restrictions prevent multi-user access or use on networks.
- eBook file is not a printable PDF, and intended for electronic use only.
- eBooks can not be returned if license code has been redeemed.
Visit: bookshelf.vitalsource.com to learn more
Please note: Instructor Tools are sold separately from the Learning Guide and eBook. The Instructor Tools for this learning guide are delivered in a downloadable PDF document containing instructor presentation files that complement the guide.
Once you have completed your purchase, you’ll receive an order confirmation email with a link to access the Instructor Tools. Within that email, click on ‘Instructor Tools’ (found under the ‘Product heading) to gain access to your PDF.
