Creo Simulate 10.0: Structural and Thermal Analysis

The Creo Simulate 10.0: Structural and Thermal Analysis guide covers the fundamentals of Structural and Thermal Analysis in Creo Simulate. It provides you with the knowledge to effectively use Creo Simulate for finite element analysis, thereby reducing design time. Many concepts apply to both Structure and Thermal analysis; a portion of this guide is specifically dedicated to Thermal analysis. This is an extensive hands-on learning guide, in which you have the opportunity to apply your knowledge through real-world scenarios and examples.

Topics Covered:
• FEA Fundamentals: P-elements and analysis convergence methods
• FEA Fundamentals: P-elements and analysis convergence methods
• Basic Modeling and Analysis
• Types of Loads and Constraints
• Idealizations: Shells and Beams
• Sensitivity and Optimization Studies
• Assembly Interfaces and Contact Analysis
• Thermal Analysis
• Modal Analysis
• Welds, Springs, and Masses
• Fasteners and Rigid Links
• Buckling Analysis

Prerequisites:

• Access to the Creo Simulate 10.0 software. The practices and files included with this guide might not be compatible with prior versions. Practice files included with this guide are compatible with the commercial version of the software, but not the student edition.
• Completion of the Creo Parametric: Introduction to Solid Modeling guide plus a minimum of 80 hours of Creo Parametric experience is recommended.

ASCENT eBooks are delivered through the VitalSource Bookshelf e-textbook platform. This format enables you to access your eBook in the following ways:

1. Download to a computer (Windows or MAC)
2. Access online (via a computer connected to the internet)
3. Download to a compatible smart phone or tablet device

Please Note:

• Dual monitors or separate reader device recommended to facilitate use with software.
• eBooks are intended for single-user use only. License restrictions prevent multi-user or network access.
• eBook is not a printable PDF and intended for electronic use only.
• eBooks cannot be returned if license code has been redeemed.

Visit: bookshelf.vitalsource.com to learn more

The Instructor Tools for this Learning Guide are delivered in a downloadable PDF document containing instructor presentation files that complement the guide.
